Compared to the X9 Plus, the recommended drone takeoff weight is increased by 1 kg. Equipped with a larger 4314 propeller, this propulsion system delivers longer flight endurance and achieves a 12% efficiency improvement within the same thrust range.
The motor features a newly designed rectangular cooling vent and a 4% weight reduction. This design helps prevent debris ingress while significantly improving heat dissipation performance.
Flatland Mode & Highland Mode
Dual-loop control architecture for optimized performance in different operating environments.
Flatland Mode
Designed for flat areas, providing stable motor RPM output and precise speed control within the operating voltage range.
Highland Mode
Designed for high-altitude areas, automatically adjusting motor RPM to adapt to high-altitude operating conditions.
Customizable on request.
Propellers are sold separately.
Technical Specifications
Arm Tube Diameter: 45 mm
KV: 80 KV
Weight: 1.8 kg
Weight with Propeller: 1,852 g
Battery: 12–14S
Recommended Thrust: 12–14 kg/rotor
Maximum Thrust: 28 kg
Recommended Propeller: 4314
CAN Protocol: Yes
Propellers are sold separately.
