The Hobbywing C8020-210KV-IPC Motor is a professional fixed-wing and VTOL UAV motor designed for cruise propulsion, large electric aircraft, industrial drones, and vertical take-off and landing platforms.
Built for demanding UAV applications, this C8020 210KV motor offers a strong balance between high thrust, efficient cooling, stable performance, and professional reliability. It is especially suitable for UAV platforms looking to replace traditional combustion engine setups with a clean, efficient, and reliable electric propulsion system.
Fixed-Wing & VTOL UAV Propulsion
The C8020-210KV-IPC is designed for both fixed-wing UAVs and VTOL drones, making it a versatile choice for aircraft requiring efficient cruise performance and reliable power delivery.
Its recommended setup includes 12S LiPo batteries, 22x10 or 23x10 propellers, and Hobbywing XRotor Pro H130A / H200A 14S BLDC IPC ESCs, making it suitable for professional UAV propulsion systems with a single-motor takeoff weight range of 35–40 kg.
IPC Intelligent Propeller Control
The IPC version is compatible with Hobbywing’s Intelligent Propeller Control system when paired with a compatible IPC ESC.
This allows users to control the propeller stopping position, helping reduce forward-flight drag and improving safety during landing, storage, and VTOL-to-cruise transition phases.
For fixed-wing and VTOL UAVs, this feature is especially useful when the propeller position must be managed to improve aerodynamic efficiency and reduce interference risks.
High Thrust & Efficient Performance
The C8020-210KV motor delivers a maximum thrust of up to 22 kg at 48V with a 23x10 propeller, making it suitable for demanding UAV platforms requiring strong propulsion performance.
With a rated thrust of 7.5 kg at 48V with a 23x10 propeller, this motor is optimized for efficient cruise operation while still providing the power needed for demanding takeoff, climb, and transition phases.
Efficient Cooling Design
The C8020 motor is engineered with an efficient cooling structure designed to improve heat dissipation during high-load operation.
Its cooling system helps reduce winding temperature rise and supports stable long-term performance, even in demanding UAV flight conditions.
This makes it a strong choice for professional aircraft where reliability and thermal stability are essential.
Rugged & Reliable Construction
The Hobbywing C8020-210KV-IPC features a robust design with IPX5 protection, waterproof bearings, high-temperature resistant materials, and a durable motor structure built for professional UAV use.
Its construction helps protect the motor from harsh operating environments such as dust, humidity, and light rain, making it suitable for industrial and outdoor UAV missions.
Professional UAV Applications
The Hobbywing C8020-210KV-IPC Motor is ideal for fixed-wing UAVs, VTOL aircraft, industrial drones, long-range UAVs, electric cruise propulsion systems, and professional unmanned aircraft platforms.
Its combination of 210KV rating, 12S compatibility, IPC function, high thrust output, and Hobbywing reliabilitymakes it a strong propulsion solution for demanding professional drone applications.
Technical Specifications
Product: Hobbywing C8020-210KV-IPC Fixed-Wing / VTOL UAV Motor
Brand: Hobbywing
Model: C8020-210KV-IPC
Motor Type: Fixed-Wing / VTOL UAV Cruise Motor
KV Rating: 210KV
Battery: 12S LiPo / 48V
Recommended Propeller: 22x10 / 23x10
Recommended ESC: Hobbywing XRotor Pro H130A / H200A 14S BLDC IPC
Rated Thrust: 7.5 kg @ 48V with 23x10 propeller
Max Thrust: 22 kg @ 48V with 23x10 propeller
Max Current: 160A
Rated Output Power: 1180W
No-Load Current: 6.93A
Resistance: 9.08mΩ
Motor Size: Φ89.1 × H59.5 mm
Stator Size: 80 × 20 mm
Slot / Pole: 24N28P
Protection Level: IPX5
Weight: Approx. 838 g with wires
Three-Phase Wire Length: 100 mm
Magnetic Encoder Cable Length: 130 mm
IPC Function: Yes, with compatible Hobbywing IPC ESC
Recommended Use: Fixed-wing UAVs, VTOL drones, long-range aircraft, industrial UAVs and professional electric propulsion systems
