The Hobbywing M5208 HP is a high-performance industrial drone motor designed for micro and small multirotor UAVs. It delivers reliable thrust, stable operation, and efficient power output for professional drone applications.
With advanced cooling, premium materials, and precise construction, the M5208 HP is built for endurance, stability, and safe long-term operation in demanding environments.
Efficient Power & Thrust
The M5208 HP delivers up to 5.4 kg of maximum thrust with the 320 KV version using an MP21×6.3″ propeller at 23 V.
The recommended thrust range is 1.4–1.6 kg per rotor.
It supports quadcopters with a total takeoff weight of 5.6–6.4 kg, making it suitable for micro and small professional UAV platforms.
Advanced Cooling & Stability
The rotor is equipped with a centrifugal fan for effective heat dissipation.
The semi-enclosed bracket and bottom cover feature dust-proof grilles to help protect the motor from debris.
This design ensures reliable operation even in high-temperature and dusty environments.
Durability & Protective Design
The high-performance iron core uses low-loss silicon steel sheets to improve efficiency and reduce energy loss.
The durable alloy main shaft and high-speed precision bearings provide stable operation and long service life.
The nickel-plated electrophoresis casing improves anti-rust and anti-corrosion protection.
NSS48 certification enhances overall reliability for demanding UAV applications.
Safety & Reliability
The motor shaft uses a cir-clip, pressure ring, and screw interlocking structure to prevent loosening during operation.
The knurled shaft design eliminates free play between shaft holes and improves assembly precision.
Built-in structural reinforcements help ensure secure and reliable long-term operation.
Load Parameters
The load parameters listed below follow the same order as the recommended propellers mentioned in this product description.
Technical Specifications
Product: Hobbywing M5208 HP Industrial Drone Motor
Application: Micro and small multirotor UAVs
KV Version: 320 KV
Maximum Thrust: Up to 5.4 kg
Recommended Thrust: 1.4–1.6 kg/rotor
Recommended Quadcopter Takeoff Weight: 5.6–6.4 kg
Battery: 6S LiPo
Recommended Propeller: 17×5.8″ / 18×6.1″ / 20×6.0″ / 21×6.3″
Cooling System: Rotor with centrifugal fan
Protection Design: Semi-enclosed bracket with dust-proof grilles
Iron Core: Low-loss silicon steel sheets
Main Shaft: Durable alloy main shaft
Bearings: High-speed precision bearings
Casing: Nickel-plated electrophoresis casing
Certification: NSS48
Protection: Anti-rust, anti-corrosion, dust-resistant, and high-temperature resistant design
What’s Included
1× Motor
Propellers are sold separately.
