The Hobbywing XRotor 3110 1150KV is a high-performance FPV brushless motor designed for powerful 8–9 inch FPV drones. With strong torque, high thrust output, and reliable cooling, it is ideal for long-range, freestyle, and cinematic FPV applications.
Built with premium materials, optimized electromagnetic design, and an efficient self-cooling rotor structure, the XRotor 3110 1150KV delivers stable power, smooth throttle response, and dependable performance during demanding flights.
High-Efficiency Heavy-Load Performance
The XRotor 3110 1150KV is optimized for strong heavy-load efficiency and stable power delivery.
With up to 4126 g of maximum thrust, it provides the power needed for large FPV drones carrying bigger batteries, HD systems, or cinematic payloads.
Its 1150KV configuration is well suited for 4–6S LiPo setups, offering strong torque, high responsiveness, and efficient control.
Efficient Cooling Design
The rotor uses a self-cooling structure to improve heat dissipation during flight.
This helps reduce temperature rise under load and extends the maximum full-load running time compared with similar motors.
Anti-Slip Propeller Mount
The motor uses a new tooth-groove anti-slip propeller mount design.
This helps prevent propeller slippage during high-throttle operation, improving safety and maintaining consistent thrust output.
Premium FPV Construction
The XRotor 3110 uses high-performance 0.2 mm silicon steel sheets for improved efficiency.
Its 220°C high-temperature resistant enameled wire improves durability under demanding FPV use.
The motor also uses strong N52 arc-shaped magnetic tiles to provide strong torque and responsive power output.
Technical Specifications
Product: Hobbywing XRotor 3110 1150KV FPV Brushless Motor
Application: 8–9 inch FPV drones, long-range, freestyle, and cinematic FPV
KV: 1150 KV
Battery: 4–6S LiPo
No-Load Current: 2.8 A / 24 V
Internal Resistance: 45 mΩ
Rated Power Output: 270 W
Maximum Current: 69 A / 6 s
Maximum Power: 1,656 W / 6 s
Maximum Thrust: 4,126 g
Weight: 88 g
Motor Size: Φ37.2 × 27 mm
Motor Structure: 12N14P
Wire Size: 18 AWG
Wire Length: 250 mm
Shaft Diameter: D5 + M5
Shaft Length: 16 mm
Motor Mounting Dimensions: Φ19 mm / 4×M3
Recommended ESC: XRotor FPV G2 65A 4in1 ESC
Recommended Propellers: HQ 8×4×3 / HQ 9×4×3
Wire Temperature Rating: 220°C
What’s Included
1× Motor
Propellers are sold separately.
