The Hobbywing XRotor 2807 1500KV is a high-performance FPV brushless motor designed for powerful 7-inch FPV drones. With strong torque, fast throttle response, and reliable cooling, it is ideal for freestyle, long-range, and cinematic FPV applications.
Built with premium materials, optimized electromagnetic design, and a self-cooling rotor structure, the XRotor 2807 1500KV delivers stable power, efficient performance, and dependable operation during demanding flights.
High-Efficiency Heavy-Load Performance
The XRotor 2807 1500KV is optimized for strong heavy-load efficiency and responsive power delivery.
With up to 2646 g of maximum thrust, it provides the power needed for 7-inch FPV drones carrying larger batteries, HD systems, or cinematic payloads.
Its 1500KV configuration is well suited for 4–5S LiPo setups, offering a balance of torque, efficiency, and punch.
Efficient Cooling Design
The rotor features a dedicated cooling structure to improve heat dissipation during flight.
This helps keep operating temperatures lower under load, supporting more consistent performance and longer motor lifespan.
Anti-Slip Propeller Mount
The motor uses a tooth-groove anti-slip propeller mount design.
This helps prevent propeller slippage during high-throttle operation, improving safety and maintaining consistent thrust output.
Premium FPV Construction
The XRotor 2807 uses high-performance 0.2 mm silicon steel laminations for improved efficiency.
Its 220°C high-temperature resistant enameled wire helps improve durability under demanding FPV use.
The robust 12N14P motor structure provides smooth operation, strong torque, and reliable throttle response.
Technical Specifications
Product: Hobbywing XRotor 2807 1500KV FPV Brushless Motor
Application: 7-inch FPV drones, freestyle, long-range, and cinematic FPV
KV: 1500 KV
Battery: 4–5S LiPo
No-Load Current: 2.27 A / 20 V
Resistance: 43.6 mΩ
Rated Power Output: 180 W
Maximum Current: 59.5 A / 7 s
Maximum Power: 1,195 W / 7 s
Maximum Thrust: 2,646 g
Weight: 58.7 g
Motor Size: Φ34 × 20.5 mm
Motor Structure: 12N14P
Wire Size: 18 AWG
Wire Length: 200 mm
Shaft Diameter: D5 + M5
Shaft Length: 15 mm
Motor Mounting Dimensions: Φ19 mm / 4×M3
Recommended ESC: XRotor FPV G2 65A 4in1 ESC
Recommended Propellers: HQ 7×3.5×3 / HQ 7×4×3
Wire Temperature Rating: 220°C
What’s Included
1× Motor
Propellers are sold separately.
