The Hobbywing XRotor 4315 360KV is a high-efficiency FPV brushless motor designed for large 15-inch FPV drones. With strong torque, high power output, and reliable cooling, it is ideal for long-range, freestyle, and cinematic FPV applications.
Built with premium materials, optimized electromagnetic design, and an efficient self-cooling rotor structure, the XRotor 4315 360KV delivers stable power, smooth throttle response, and dependable performance during demanding flights.
High-Efficiency Power Performance
The XRotor 4315 360KV is optimized for strong torque and high-efficiency power delivery.
With up to 7.18 kg of maximum thrust, it provides reliable lift for large FPV drones carrying bigger batteries, HD systems, or cinematic payloads.
Its 360KV configuration is designed for 8S LiPo setups, offering strong power output, smooth throttle response, and stable control.
Efficient Cooling Design
The motor’s outer rotor uses a self-cooling structure to help dissipate coil heat during flight.
This supports lower operating temperatures, improved efficiency, and longer motor lifespan during demanding FPV use.
Anti-Slip Propeller Mount
The propeller mount incorporates a tooth-groove anti-slip structure.
This helps prevent propeller slippage and rotation loss, improving flight safety and maintaining consistent thrust output.
Premium FPV Construction
The XRotor 4315 uses high-performance 0.2 mm stator core laminations for improved efficiency.
Its 220°C high-temperature resistant enameled wire improves durability under high-load FPV operation.
The multi-strand winding design improves slot fill rate, helping reduce motor temperature at the same power output.
Strong arc-shaped magnets increase magnetic flux density and provide powerful, precise motor response during flight.
Technical Specifications
Product: Hobbywing XRotor 4315 360KV FPV Brushless Motor
Application: Large FPV drones, long-range, freestyle, and cinematic FPV
KV: 360 KV
Battery: 8S LiPo
No-Load Current: 1.8 A
Internal Resistance: 57 mΩ
Rated Power Output: 560 W
Maximum Current: 56.8 A / 26 s
Maximum Power: 1,813.5 W / 26 s
Maximum Thrust: 7.18 kg
Weight with Wires: 250 g
Motor Size: Φ50.8 × 36.3 mm
Stator Size: Φ43 × 15 mm
Motor Structure: 12N14P
Bearing: MR126ZZ
Wire Size: 16 AWG
Wire Length: 500 mm
Shaft Diameter: Φ6 mm
Shaft Length: 25 mm
Motor Mounting Dimensions: Φ30 mm / 4×M4
Recommended ESC: XRotor 80A 4in1 8S Lite AT RTF
Recommended Propeller: HQ15×7×3
Recommended Thrust Range: 3–6 kg/rotor
Wire Temperature Rating: 220°C
Isolation Test: 500 V AC high-voltage resistance test
What’s Included
1× Motor
1× Screw Set
Propellers are sold separately.
