HOBBYWING

H6M-130KV

€0.00
Tax included
Efficient operating range of 2–4 kg per rotor, delivering up to 7 kg maximum thrust. Integrated propulsion architecture designed for industrial UAV applications. Propeller not included. Recommended propeller: MSC 22×7.8.
€0.00
Tax included
Quantity
Add to Wishlist
Add to Compare

Hobbywing H6M Integrated Propulsion System

The Hobbywing H6M integrated propulsion system is engineered for professional multirotor drones, combining motor and ESC into a single compact unit for higher efficiency, reliability, and simplified installation. Designed for industrial use, it ensures safe and stable performance for aerial photography, mapping, inspection, and public safety missions.

Key Features

Efficient & Reliable Performance

  • Rated thrust: 2.5 kg per rotor with efficiency up to 9.3 g/W

  • Integrated motor + ESC design ensures smoother operation and simplified assembly

  • Self-developed FOC sine wave ESC delivers precise, quiet, and efficient control

Redundant & Safe Control

  • Dual throttle redundancy (PWM + CAN) for secure, fail-safe operation

  • Seamless throttle switching in ≤16 ms to ensure continuous flight safety

  • Real-time fault storage and monitoring with automatic system logging

Advanced Cooling & Durability

  • Built-in centrifugal fan with cascading air outlets boosts cooling efficiency by 20%

  • Operates 15–20°C cooler than conventional systems

  • Waterproof and dustproof with IP45 protection rating

Industrial-Grade Materials

  • Uses H+ high-temperature resistant enameled wire (>200°C)

  • Tested for extreme environments from -20°C to +65°C

  • Rugged design ensures long service life in demanding conditions

Optimized Design

  • CD-pattern rotor design for improved recognition and heat dissipation

  • Lightweight and modular structure for easier maintenance

  • Compatible with Hobbywing data link for system diagnostics and tuning

*Propellers are sold separately

Data sheet

KV
130KV
CAN Protocol
CAN
Communication Protocol
CAN
ESC
Integrated
Protection Rating
IP45
Max thrust
6.5kg/Rotor
Rated Thrust
2.5 kg per rotor
Ambient temperature
-20°Cto+65°C
