The Hobbywing XRotor 2207.5 1980KV is a high-performance FPV brushless motor designed for racing and aggressive freestyle drones. With ultra-fast throttle response, strong power output, and precise cornering performance, it is ideal for pilots looking for maximum responsiveness on 5-inch FPV builds.
Built with premium materials, optimized electromagnetic design, and efficient heat dissipation, the XRotor 2207.5 1980KV delivers reliable performance, stable response, and long service life for demanding FPV applications.
High-Power Racing Performance
The 1980KV version is optimized for high power output and ultra-fast response.
It delivers up to 1868 g of maximum thrust, making it ideal for racing, sharp cornering, and dynamic FPV flying.
Fast & Precise Throttle Response
The optimized electromagnetic design provides responsive acceleration and precise motor control.
This helps improve cornering accuracy, throttle feel, and overall flight performance during aggressive maneuvers.
Efficient Heat Dissipation
The motor features a self-cooling propeller mount design to help dissipate coil heat during flight.
This supports lower operating temperatures, improved efficiency, and extended motor lifespan.
Premium Materials
The XRotor 2207.5 uses high-performance 0.2 mm stator laminations for improved efficiency and reliability.
Its 220°C high-temperature resistant enameled wire helps improve durability under high-load FPV operation.
Strong arc-shaped magnets increase magnetic flux density and provide powerful, responsive motor output.
Anti-Slip Propeller Mount
The innovative anti-slip tooth structure on the propeller mount helps prevent propeller slippage.
This improves safety, reduces rotation loss, and ensures more consistent thrust delivery during aggressive flying.
Technical Specifications
Product: Hobbywing XRotor 2207.5 1980KV FPV Brushless Motor
Application: FPV racing and aggressive freestyle drones
KV: 1980 KV
Battery: 6S LiPo
No-Load Current: 3.2 A / 24 V
Maximum Current: 49 A / 3 s
Maximum Power: 1,166 W / 3 s
Maximum Thrust: 1,868 g
Weight with Wires: 38 g
Motor Size: Φ28 × H19.9 mm
Stator Size: Φ22.5 × 7.6 mm
Motor Structure: 12N14P
Wire Size: 20 AWG
Wire Length: 150 mm
Internal Resistance: 65 mΩ
Shaft Diameter: Φ5 mm + M5
Shaft Length: 12 mm
Motor Mounting Dimensions: 4×M3 @ Φ16 mm
Recommended ESC: XRotor FPV G2 65A 4in1 ESC
Recommended Propellers: GF51466 / GF51477 / HQ 4.9×3.7×3 / HQ 5.1×4×3
What’s Included
1× Motor
Propellers are sold separately.
